Keysight B1500A Configuration and Connection Guide
1-27
B1500A Product Configuration
Upgrade products for the B1500A series
1.4.4 Maximum Module Configuration
The B1500A can contain any combination of the following module. Then the total power
consumption of all SMU modules cannot exceed 84 W.
• Up to 10 MPSMU
• Up to 10 HRSMU
• Up to 4 HPSMU
• Up to 4 MCSMU
• One MFCMU
•Up to 5 HVSPGU
• Up to 5 WGFMU
1.4.5 Limitation by installing B1500AU-030 WGFMU
The following tables show the limitation of installing WGFMU and additional
SMU/CMU/HVSPGU. When WGFMU is installed into B1500A frame, Module
configuration needs to follow all the conditions below.
• Total Number of slots must be under 10 slots
• The maximum SMU/CMU/HVSPGU/WGFMU numbers need to meet the followin
g
fo
rmula due to the limitation of the power consumption
Total number of [Number of Module * Factor for each module] must be unde
r 59.
(In
cluding 59)
• For example, configuration with 5*WGFMU and 5*MPSMU [total factor will
be 60.]
are not
acceptable.
Table 1-26 Module Factor list
NOTE Module locations after servicing
After the module installation, upgrade, and so on, the B1500A will be returned with the
module configuration decided by the rule shown in Table 1-25. If you want to change the
module locations, consult the service personnel before servicing.
Option Upgrade Module Factor for power consumption
B1500A-A10 B1500AU-010 High Power SMU (HPSMU) 14
B1500A-A11 B1500AU-11B Medium Power SMU (MPSMU) 2
B1500A-A17 B1500AU-017 High Resolution SMU (HRSMU) 2
B1500A-A1A B1500AU-141 Medium Current SMU (MCSMU) 5
B1500A-A20 B1500AU-020 Multi Frequency CMU (MFSMU) 7
B1500A-A25 B1500AU-025 High Voltage SPGU (HVSPGU) 12
B1500A-A30 B1500AU-030 Waveform Generator FMU (WGFMU) 10
