Keysight Technologies B1500A Configuration And Connection Guide

4-4
Keysight B1500A Configuration and Connection Guide
Connection and Ordering Examples
Two terminal device
4.1.2 General IV/CV characterization
Figure 4-2 General IV/CV configuration
Table 4-4 Target device and application
Table 4-5 Key specification
Device Application Note
Diode I
F
-V
F
, I
R
-V
R
, Breakdown, C-V, C-f, C-t
Resister R-I, R-V 2-wire or 4-wire
Item Range Note
Maximum I/V range 100 mA / 100 V
Minimum I/V resolution 10 fA / 0.5 μV
CV frequency range 1 kHz to 5 MHz
Maximum DC bias to CV 100 V MPSMU and SCUU is required.
MPSMU
SCUU cable
(N1301A-102)
Sense
Force
B1500A
MPSMU
Sense
Force
Interlock cable
MFCMU
Hpot
Hcur
Lpot
Lcur
12
Triaxial cable
SCUU
(N1301A-100)
CMUH
Force1/
CMUL
Force2/
Sense1
Sense2
GSWU
Connector plate
Fixture/Prober
DUT
AC
Interlock
GSWU (N1302A-200)
GSWU cable (N1302A-201/202)
