Keysight B1500A Configuration and Connection Guide
4-5
Connection and Ordering Examples
Two terminal device
Table 4-6 Configuration Example
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A00 Empty package for custom solution, contains no measurement module 1
B1500A-A11 MPSMU add-on package, adds one MPSMU and two triaxial cables 2
B1500A-A20 Capacitance measurement add-on package, adds the MFCMU and one CMU
cable
1
N1301A Accessories for CMU 1
N1301A-100 SMU CMU unify unit (SCUU) 1
N1301A-102 SCUU cable, 3 m 1
N1301A-110 SCUU magnetic stand (Optional) 1
N1301A-200 Guard switch unit (GSWU) 1
N1301A-201/202 GSWU cable, 1.5 m or 3 m 1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
To Next Page
