Keysight Technologies B1500A Configuration And Connection Guide

1-8
Keysight B1500A Configuration and Connection Guide
B1500A Product Configuration
Options of B1500A series
B1500A-A30 Add-on package - WGFMU 1ea,
Remote sense unit 2ea, cables
• WGFMU add-on package adds one WGFMU,
two RSU, and two RSU cables
• Cable length 1.5 m
or 3.0 m is specified by
option 015 or 030.
B1500A-A31 Add-on package - WGFMU 1ea,
Connector adaptor, Remote sense unit
2ea, cables
• WGFMU add-on package adds one WGFMU,
two RSU, and accessories for connector plate.
See Table 1-19.
• Cable length 1.5 m or 3.0 m is specified by
opti
on 015 or 030.
B1500A-A3P Add-on package - Probe cable kit for
WGFMU (8 probe cables. WGMU not
included)
• WGFMU probe cable kit adds cables for prober
.
See Table 1-20.
• This option does not include the WGFMU
module.
B1500A-A5F Add-on package - Test fixture for
packaged device (16442B 1ea)
• Test fixture for package device measurement,
adds one 16442B Parametric Test Fixture.
• See Table 1-21 for furnished accessories.
Specify the cable length (mandatory)
B1500A-015 1.5 m cable • 1.5 m cable length (for mainframe bundled
cables and for package options)
B1500A-030 3.0 m cable • 3.0 m cable length (for mainframe bundled
cables and for package options)
Specify the power line frequency (mandatory)
B1500A-050 50Hz line frequency
B1500A-060 60Hz line frequency
Select calibration options (optional)
B1500A-A6J ANSI Z540 compliant calibration • ANSI Z540 compliant calibration
B1500A-UK6 Commercial cal. certificate w/ test data • Test Data for ISO 9001/2 Commerci
al
Calibration. This option provides measurement
test data for the standard commercial calibration
and test equipment trace information.
Specify the language of the paper manuals if you need (optional)
B1500A-ABA Paper manual set, English • Printed manuals are optional. Order this option
to get the paper manuals. Contains B1500A user
guide, Plug & Play driver user guide, self-paced
training manual, EasyEXPERT user guide, and
programming guide.
B1500A-ABJ Paper manual set, Japanese
Select the read-only drive if you need (optional)
Model/
Option
Description OP Instruction
