Keysight B1500A Configuration and Connection Guide
4-25
Connection and Ordering Examples
Four terminal device
Table 4-34 Target device and application
Table 4-35 Key specification
Table 4-36 Configuration Example
Device Application Note
Memory Endurance test, Erase and V
th
test, Write
and V
th
test, Retention test, Word disturb
test
Requires 2 or 3 pulse channels
Item Range Note
Maximum I/V range 100 mA / 100 V
Minimum I/V resolution 10 fA / 0.5 μV
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A04 Flash memory cell measurement basic package 1
B1500A-A25 HVSPGU add-on package, adds one HVSPGU and two SPGU cables 1
16440A SMU/PGU pulse generator selector 1
16440A-003 Control cable, 40 cm for second selector 1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
