Keysight B1500A Configuration and Connection Guide
4-27
Connection and Ordering Examples
Configuration example of WGFMU
Table 4-39 Configuration Example
Stress DC stress / AC stress
Maximum DC I/V range 100 mA / 100 V
Minimum I/V resolution 10 fA / 0.5 μV
Item Range Note
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A00 Empty package for custom solution, contains no measurement module 1
B1500A-A11 MPSMU add-on package, adds one MPSMU and two triaxial cables 2
B1500A-A31 WGFMU add-on package with connector adapters 1
(B1500A-A30) WGFMU add-on package, If you put RSU on external shield box. 1
B1500A-A3P WGFMU probe cable kit 1
To Next Page
