Keysight B1500A Configuration and Connection Guide
4-17
Connection and Ordering Examples
Four terminal device
Table 4-24 Configuration Example
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A03 High power package, contains two HPSMU, two MPSMU, and eight triaxial
cables
1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
