Keysight B1500A Configuration and Connection Guide
1-11
B1500A Product Configuration
Furnished accessories
GNDU Kelvin adapter 1 GNDU Kelvin adapter must be directly connected to the B1500A GNDU
connector for taking out the GNDU Force and Sense to the individual
connectors. Then the GNDU cable must be used for extending the GNDU
Force. And the triaxial cable must be used for the Sense.
Triaxial cable 1 Cable length 1.5 m or 3.0 m is specified by the option B1500A-015 or
B1500A-030.
Power cable 1 Power cable for the B1500A
License Sheet
1
SWS License-to-use for EasyEXPERT group+ software.
SMU number label
1 SMU number label, only for the B1500A installed with SMU.
PG number label 1 PG number label, only for the B1500A installed with HVSPGU
Description Qty. Note
