Keysight B1500A Configuration and Connection Guide
2-7
B1500A Accessories
Accessories for the B1500A
NOTE Connect the Ref Out/In, Sync Out/In, and Trig Out terminals to the specified terminal
properly. Connecting to the other terminal may result in damage to the SPGU.
16445A SMU PGU selector connection adapter, furnished
with digital I/O control cable
16445A-001 Control cable for B1500A to 16445A, 1.5 m
16445A-002 Control cable for B1500A to 16445A, 3 m
16493G-001 Digital I/O control cable, 1.5 m
16493G-002 Digital I/O control cable, 3 m
Model/Option Description Additional Information
To Next Page
