Keysight B1500A User’s Guide, Ed ition 14 4- 37
Specifications
Hardware
• WGFMU supplemental data
•RSU SMU path
Leakage current: < 100 pA
Residual resistance: < 300 m
• Jitter: < 1 ns
• Skew between channels: < 3 ns, under no electrostatic discharge condition
• Trigger output skew: < 3 ns
• Current range change time: < 150 s
This is the time until the measured current settles within ± 0.3 % of the final
result value after the range change.
•
Minimum timing parameters for current measurement : See Table 4-22.
•
Minimum timing parameters for voltage measurement : See Table 4-23.
Table 4-17 Measurement functions, voltage forcing, voltage measurement, and current
measurement
Mode Function V force ranges
V measure
ranges
I measure
ranges
Fast IV V force/
I measure,
V force/
V measure
-3 V to +3 V,
-5 V to +5 V,
-10 V to 0 V,
0 V to +10 V
-5 V to +5 V,
-10 V to
+10 V
1 A, 10 A,
100 A,
1 mA, 10 mA
PG V force/
V measure
-3 V to +3 V,
-5 V to +5 V
-5 V to +5 V -
DC V force/
I measure,
V force/
V measure
-3 V to +3 V,
-5 V to +5 V,
-10 V to 0 V,
0 V to +10 V
-5 V to +5 V,
-10 V to
+10 V
1 A, 10 A,
100 A,
1 mA, 10 mA
SMU pass
through
Measurement
using SMU
Maximum
± 25 V
- Maximum
± 100 mA
