Waveform Generator 17
Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 221
3 In the Waveform Generator Settings Menu, press the Out Load softkey and turn
the Entry knob to select:
• 50 Ω
• High-Z
The output impedance of the Gen Out BNC is fixed at 50 ohms. However, the
output load selection lets the waveform generator display the correct amplitude
and offset levels for the expected output load.
If the actual load impedance is different than the selected value, the displayed
amplitude and offset levels will be incorrect.
To use waveform generator logic presets
With logic level presets, you can easily set the output voltage to TTL, CMOS
(5.0V), CMOS (3.3V), CMOS (2.5V), or ECL compatible Low and High levels.
1 If the Waveform Generator Menu is not currently displayed on the
oscilloscope's softkeys, press the [Wave Gen] key.
2 In the Waveform Generator Menu, press the Settings softkey.
3 In the Waveform Generator Settings Menu, press the Logic Presets softkey.
4 In the Waveform Generator Logic Level Presets Menu, press one of the softkeys
to set the generated signal's Low and High voltages to logic compatible levels:
Softkey (logic levels) Low level High level, 50 ohm
expected output load
High level, high-Z
expected output load
TTL 0V +2.5V (TTL compatible) +5V
CMOS (5.0V) 0V Not Available +5V
CMOS (3.3V) 0V +2.5V (CMOS
compatible)
+3.3 V
CMOS (2.5V) 0 V +2.5 V +2.5 V
ECL -1.7 V -0.8 V (ECL compatible) -0.9 V
