Getting Started 1
Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 45
Learn the Oscilloscope Display
The oscilloscope display contains acquired waveforms, setup information,
measurement results, and the softkey definitions.
5. Calibration
protect button
See “To perform user calibration" on page 257.
6. EXT TRIG IN
connector
External trigger input BNC connector. See “External Trigger Input" on
page 152 for an explanation of this feature.
8. USB Device
port
This port is for connecting the oscilloscope to a host PC. You can issue
remote commands from a host PC to the oscilloscope via the USB device
port. See “Remote Programming with Keysight IO Libraries" on
page 274.
7. USB Host port This port functions identically to the USB host port on the front panel. USB
Host Port is used for saving data from the oscilloscope and loading
software updates. See also USB Host port (see page 41).
