Keysight InfiniiVision 2000 X-Series Oscilloscopes

User's Guide

24 I2C/SPI Triggering and

Serial Decode

Setup for I2C Signals / 317

I2C Triggering / 318

I2C Serial Decode / 322

Setup for SPI Signals / 325

SPI Triggering / 329

SPI Serial Decode / 331

I2C/SPI triggering and serial decode requires Option EMBD or the DSOX3EMBD

upgrade.

Setup for I2C Signals

C (Inter-IC bus) signals setup consists of connecting the oscilloscope to the

serial data (SDA) line and the serial clock (SCL) line and then specifying the input

signal threshold voltage levels.

To set up the oscilloscope to capture I

C signals, use the Signals softkey which

appears in the Serial Decode Menu:

1 Press [Label] to turn on labels.

2 Press [Serial].

NOTE

Only one SPI serial bus can be decoded at a time.
