Reference 22
Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 285
Environmental Conditions
Probes and Accessories
For a list of the probes and accessories that are compatible with the 2000 X-Series
oscilloscopes, see the data sheet at: www.keysight.com/find/2000X-Series
Because the 2000 X-Series oscilloscopes do not have a ring around the BNC
connector for identifying probes, you must set the probe attenuation factor
manually. See “Setting Analog Channel Probe Options" on page 67.
Maximum input voltage at digital channels
±40 V peak
Environment Indoor use only.
Ambient
temperature
Operating 5 °C to +55 °C; non-operating –40 °C to +71 °C
Humidity Operating: Up to 80% RH at or below +40 °C. Up to 45% RH up to +50 °C.
Non-operating: Up to 95% RH up to +40 °C. Up to 45% RH up to +50 °C.
Altitude Operating and non-operating to 4,000 m (13,123 ft)
Overvoltage
Category
This product is intended to be powered by MAINS that comply to Overvoltage
Category II, which is typical of cord-and-plug connected equipment.
Pollution Degree The InfiniiVision 2000/3000 X-Series oscilloscopes may be operated in
environments of Pollution Degree 2 (or Pollution Degree 1).
Pollution Degree
Definitions
Pollution Degree 1: No pollution or only dry, non-conductive pollution occurs.
The pollution has no influence. Example: A clean room or climate controlled
office environment.
Pollution Degree 2. Normally only dry non-conductive pollution occurs.
Occasionally a temporary conductivity caused by condensation may occur.
Example: General indoor environment.
Pollution Degree 3: Conductive pollution occurs, or dry, non-conductive
pollution occurs which becomes conductive due to condensation which is
expected. Example: Sheltered outdoor environment.
