Reference 22
Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 287
Other Options Available
Upgrading to an MSO
A license can be installed to activate the digital channels of an oscilloscope that
was not originally ordered as a mixed-signal oscilloscope (MSO). A mixed signal
oscilloscope has analog channels plus 8 time-correlated digital timing channels.
EDK Educator's Kit
Provides training signals on the oscilloscope's Demo
terminals and a lab guide/tutorial for education
environments.
Order DSOXEDK.
EMBD Embedded Serial Triggering and Analysis (I2C, SPI). Order DSOX2EMBD.
MASK Mask Limit Test
Lets you create a mask and test waveforms to determine
whether they comply to the mask.
Order DSOX2MASK.
mem4M Memory Upgrade.
It shows the total memory depth (4 Mpts interleaved).
Order DSOX2MEMUP.
MSO Mixed Signal Oscilloscope (MSO). Upgrade a DSO to an MSO.
Adds 8 digital channels. You do not have to install any
hardware.
Order DSOX2MSO.
The digital probe cable kit is supplied with
the MSO license.
SGM Segmented Memory.
Lets you capture infrequent or burst signals with great
resolution by eliminating the capture of your signal's
"inactivity".
Order DSOX2SGM.
WAVEGEN Waveform Generator. Order DSOX2WAVEGEN.
Table 4 Licensed Options Available (continued)
License Description After purchase model number, notes
Table 5 Calibration Option
Option Order
A6J ANSI Z540 Compliant Calibration
