Parameter Typical Return
0 to 1.023 <delay value>
Specifies a delay of 60 milliseconds: OUTP:COUP:DOFF0.06
OUTPut[:STATe]:COUPle:MAX:DOFFset?
Returns the delay offset required for this instrument. As a minimum, the
OUTPut:COUPle:DELay:OFFSet value must be set to the maximum delay offset returned for any
coupled output.
Parameter Typical Return
(none) <offset value>
Returns the maximum delay offset: OUTP:COUP:MAX:DOFF?
OUTPut[:STATe]:COUPle:OFF:SOURce EXPRession<1-8>
OUTPut[:STATe]:COUPle:OFF:SOURce?
OUTPut[:STATe]:COUPle:ON:SOURce EXPRession<1-8>
OUTPut[:STATe]:COUPle:ON:SOURce?
Sets the source that drives the OFFCouple and ONCouple signals to an expression. The output state
changes when the selected source transitions from false to true.
Parameter Typical Return
EXPRession<1-8> EXPR<1-8>
Sets the OFFCouple source to an expression: OUTP:COUP:OFF:SOUR EXPR1
OUTPut[:STATe]:DELay:FALL <value>|MIN|MAX
OUTPut[:STATe]:DELay:FALL? [MIN|MAX]
OUTPut[:STATe]:DELay:RISE <value>|MIN|MAX
OUTPut[:STATe]:DELay:RISE? [MIN|MAX]
Specifies the delay in seconds that the instrument waits before turning the output on (rise) or off (fall).
This allows multiple instruments to turn on or off in sequence. The output will not turn on or off until
its delay time has elapsed. This command affects on-to-off state transitions. It does NOT affect
transitions to off caused by protection functions. Delay times can be programmed with the following
resolution:
Range in seconds Resolution Range in seconds Resolution
0 to 1.023E–4 100 nanoseconds 1.03E–1 to 1.023E+0 1 millisecond
1.03E–4 to 1.023E–3 1 microsecond 1.03E+0 to 1.023E+1 10 milliseconds
1.03E–3 to 1.023E–2 10 microseconds 1.03E+1 to 1.023E+2 100 milliseconds
1.03E–2 to 1.023E–1 100 microseconds 1.03E+2 to 1.023E+3 1 second
6 SCPI Programming Reference
249 Keysight N6900/N7900 Series Operating and Service Guide
