Specifications - Keysight N6900 Series
1 kW Specifications N6950A N6951A N6952A N6953A N6954A
DC Ratings
Voltage source:
Current source:
Current sink 10% rating:
Current sink 100% rating:
1
Power:
2
0 to 9 V
0 to 100 A
-10 A
-100 A
900 W
0 to 20 V
0 to 50 A
-5 A
-50 A
1 kW
0 to 40 V
0 to 25 A
-2.5 A
-25 A
1 kW
0 to 60 V
0 to 16.7 A
-1.67 A
-16.7 A
1 kW
0 to 80 V
0 to 12.5 A
-1.25 A
-12.5 A
1 kW
Output ripple & noise
3
CV rms:
CV peak-to-peak:
1 mV
9 mV
Load regulation
Voltage:
Current:
0.5 mV
8 mA
0.75 mV
3 mA
1.5 mV
1 mA
2 mV
1 mA
2 mV
0.8 mA
Voltage programming &
measurement accuracy
4, 5, 6
Lead drop ≤1 V max:
Lead drop ≤25% of V rating:
Lead drop ≤1 V max:
Lead drop ≤25% of V rating:
0.03% +1.5 mV
0.03% +1.9 mV
0.03% +1 mV
0.03% +1.4 mV
0.03% +3 mV
0.03% +4 mV
0.03% +2 mV
0.03% +3 mV
0.03% +6 mV
0.03% +7.9 mV
0.03% +4 mV
0.03% +5.9mV
0.03% +9 mV
0.03% +12 mV
0.03% +6 mV
0.03% +9 mV
0.03% +12 mV
0.03% +16 mV
0.03% +8 mV
0.03% +12mV
Current programming &
measurement accuracy:
4
Accuracy:
0.1% +30 mA
0.04% +15 mA
0.1% +15 mA
0.04% +8 mA
0.1% +8 mA
0.04% +4 mA
0.1% +5 mA
0.04% +2.5 mA
0.1% +4 mA
0.04% +2 mA
Current low range
measurement accuracy:
0.05% +3 mA 0.05% +1 mA 0.05% +0.6 mA 0.05% +0.3 mA 0.05%+0.25 mA
Transient response
7
Recovery Time:
Settling band:
100 µs
150 mV
100 µs
150 mV
100 µs
100 mV
100 µs
150 mV
100 µs
200 mV
2 kW Specifications N6970A N6971A N6972A N6973A N6974A
DC Ratings
Voltage source:
Current source:
Current sink 10% rating:
Current sink 100% rating:
1
Power:
2
0 to 9 V
0 to 200 A
-20 A
-200 A
1.8 kW
0 to 20 V
0 to 100 A
-10 A
-100 A
2 kW
0 to 40 V
0 to 50 A
-5 A
-50 A
2 kW
0 to 60 V
0 to 33.3 A
-3.33 A
-33.3 A
2 kW
0 to 80 V
0 to 25A
-2.5 A
-25 A
2 kW
Output ripple & noise
3
CV rms:
CV peak-to-peak:
1 mV
9 mV
Load regulation
Voltage:
Current:
0.5 mV
15 mA
0.75 mV
6 mA
1.5 mV
1.5 mA
2 mV
1.5 mA
2 mV
1.5 mA
Keysight N6900/N7900 Series Operating and Service Guide 41
1 Quick Reference

Keysight Technologies N6972A with Option 301 Specifications

General

Brand	Keysight Technologies
Model	N6972A with Option 301
Category	Power Supply
Language	English
