Keysight Technologies N6972A with Option 301

N6976A
N6976A Test Record Report Number ______ Date__________
Test Description Model Min. Specs Results Max. Specs
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
+ 103 mV
Vout – 17 mV
119.947 V
Vout – 53 mV
_______
_______
_______
_______
+ 137 mV
Vout + 17 mV
120.053 V
Vout + 53 mV
CV Load Effect: – 4 mV _______ + 4 mV
CV Ripple and Noise
peak-to-peak:
rms:
N/A
N/A
_______
_______
+ 9 mV
+ 1 mV
Transient response @ 100 µs: – 300 mV _______ + 300 mV
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
– 5 mA
Iout – 5 mA
16.6783 A
Iout – 0.0217 A
_______
_______
_______
_______
+ 5 mA
Iout + 5 mA
16.7217 A
Iout + 0.0217 A
CC Load Effect: – 1 mA _______ + 1 mA
Current Sink Tests
10% of current rating:
100% of current rating:
– 1.6767 A
– 16.7217 A
_______
_______
– 1.6633 A
– 16.6783 A
N6976A Settings
Voltage Programming & Readback Min:
Voltage Programming & Readback High:
CV Load Effect, CV Ripple and Noise:
Transient Response:
Current Programming & Readback Min:
Current Programming & Readback High:
CC Load Effect:
10% of current rating (Isink):
100% of current rating (Isink):
Voltage priority: 120 mV, 16.7 A
Voltage priority: 120 V, 16.7 A
Voltage priority: 120 V, 16.7 A
Voltage priority: 120 V, 8.35 A to 16.7 A
Current priority: 120 V, 0 A
Current priority: 120 V, 16.7 A
Current priority: 120 V, 16.7 A
Current priority: 120 V, - 1.67 A
External supply: 120 V,1.837 A
Current priority: 120 V, - 16.7 A
External supply: 120 V,18.37 A
Keysight N6900/N7900 Series Operating and Service Guide 337
7 Verification and Calibration
