Before Installation or Use
Inspect the Unit
When you receive your APS unit, inspect it for any obvious damage that may have occurred during
shipment. If there is damage, notify the shipping carrier and nearest Keysight Sales and Support Office
immediately. Refer to www.keysight.com/find/assist.
Until you have checked out the unit, save the shipping carton and packing materials in case the unit
has to be returned.
Check for Items Supplied
Before getting started, check the following list and verify that you have received these items.If
anything is missing, please contact your nearest Keysight Sales and Support Office.
N6900/N7900 Items Description Part Number
Power Cord A power cord suitable for your location Call the Keysight Sales and Sup-
port Office
Product Reference CD Includes software and documentation
Keysight N7900-13601
Automation-Ready CD Contains Keysight IO Libraries Suite Keysight E2094N
Digital connector plug 8-pin connector for the digital port Keysight 1253-6408;
Phoenix Contact 1840421
Sharing connector plug 3-pin connector for the sharing port Keysight 0360-3038;
Phoenix Contact 1840379
Sense cable 2-pin + and - sense wire cable Keysight 5190-4501
Plug only: Keysight 1253-8485;
Phoenix Contact 1952267
Safety cover Safety cover for output bus bars Keysight 5003-1126
Calibration certificate Calibration certificate referenced to serial
number
None
Hardware kit
1-sethardware for high current bus bars
1-sethardware for low current bus bars
Keysight 5067-6031
N7909A Items Description Part Number
Installation sheet Contains installation information N7909-90001
Dissipator power cable
plugs
2 connector plugs for fabricated cable Keysight 0360-3050;
Phoenix Contact 1718481
Dissipator interface cable 1 m cable (CAT6A) for interface con-
nections
Keysight 8121-2314
2 Installing the Instrument
66 Keysight N6900/N7900 Series Operating and Service Guide
