1 kW Specifications N7950A N7951A N7952A N7953A N7954A
Current programming &
measurement accuracy:
4
0.04% +15 mA 0.04% +8 mA 0.04% +4 mA 0.04%+2.5 mA 0.04% +2 mA
Current low range measurement
accuracy: 0.05% +3 mA 0.05% +1 mA 0.05% +0.6 mA 0.05% +0.3 mA 0.05% +0.25mA
Transient response
7
Recovery Time:
Settling band:
100 µs
150 mV
100 µs
150 mV
100 µs
100 mV
100 µs
150 mV
100 µs
200 mV
2 kW Specifications
N7970A N7971A N7972A N7973A N7974A
DC Ratings
Voltage source:
Current source:
Current sink 10% rating:
Current sink 100% rating:
1
Power:
2
0 to 9 V
0 to 200 A
-20 A
-200 A
1.8 kW
0 to 20 V
0 to 100 A
-10 A
-100 A
2 kW
0 to 40 V
0 to 50 A
-5 A
-50 A
2 kW
0 to 60 V
0 to 33.3 A
-3.33 A
-33.3 A
2 kW
0 to 80 V
0 to 25A
-2.5 A
-25 A
2 kW
Output ripple & noise
3
CV rms:
CV peak-to-peak:
1 mV
9 mV
Load regulation
Voltage:
Current:
0.5 mV
15 mA
0.75 mV
6 mA
1.5 mV
1.5 mA
2 mV
1.5 mA
2 mV
1.5 mA
Voltage programming &
measurement accuracy
4, 5, 6
Lead drop ≤1 V max:
Lead drop ≤25% of V rating:
0.03% +1 mV
0.03% +1.4 mV
0.03% +2 mV
0.03% +3 mV
0.03% +4 mV
0.03% +5.9mV
0.03% +6 mV
0.03% +9 mV
0.03% +8 mV
0.03% +12mV
Current programming &
measurement accuracy:
4
0.04% +30 mA 0.04% +15 mA 0.04% +8 mA 0.04% +5 mA 0.04% +4 mA
Current low range measurement
accuracy: 0.05% +6 mA 0.05% +2 mA 0.05% +1.2 mA 0.05% +0.6 mA 0.05% +0.5 mA
Transient response
7
Recovery Time:
Settling band:
100 µs
150 mV
100 µs
150 mV
100 µs
100 mV
100 µs
150 mV
100 µs
200 mV
1
Current sinking up to 100% of rated current requires one power dissipator for 1 kW models, and two power dissipators for 2 kW models. 2
kW models with one power dissipator can sink 50% of their rated current.
2
Maximum continuous power available is derated at 1% of rating per degree C from 40°C to 55°C
3
From 20 Hz to 300 kHz for rms noise; from 20 Hz to 20 MHz for peak-to-peak noise
4
At 23°C ±5°C after a 30 minute warm-up; measurement NPLC=1; valid for 1 year, see Calibration Interval
5
With resistance programming enabled, the voltage programming offset component increases by a factor of 3.15
6
Load lead drop applies to each load lead
7
Time to recover to within the settling band following a load change from 50% to 100% of full load (10 µs rise time)
Keysight N6900/N7900 Series Operating and Service Guide 43
