1 kW Characteristics
N6950A N6951A N6952A N6953A N6954A
Output current noise
5
CC rms: 15 mA 15 mA 15 mA 15 mA 15 mA
Common mode current
5
CC rms:
CC peak-to-peak:
2 mA
10 mA
1 mA
10 mA
1 mA
10 mA
1 mA
10 mA
1.5 mA
10 mA
Voltage up-
programming time
6
10% to 90%:
Settling time:
8
10% to 90%:
Settling time:
8
3 ms
10 ms
0.5 ms
1 ms
Voltage down-
programming time
7
90% to 10%:
Settling time:
8
90% to 10%:
Settling time:
8
3 ms
10 ms
0.35 ms
0.8 ms
Current up- and down-
programming time
9
10% to 90%:
90% to 10%:
2.5 ms
2.5 ms
Output-on delay time
Voltage priority:
Current priority:
12 ms (38 ms with Relay Option on)
14 ms (46 ms with Relay Option on)
Line regulation
Voltage:
Current:
< 10 µV
< 10 µA
Small signal bandwidth
Voltage programming:
10
Current programming:
11
Voltage measurement:
Current measurement:
DC to 1 kHz (-1dB);DC to 2 kHz (-3dB)
DC to 70 Hz (-1dB);DC to 120 Hz (-3dB)
DC to 14 kHz (-1dB);DC to 25 kHz (-3dB)
DC to 14 kHz (-1dB);DC to 25 kHz (-3dB)
2 kW Characteristics
N6970A N6971A N6972A N6973A N6974A
Minimum compliance limits
Voltage priority:
Current priority:
200 mA
9 mV
100 mA
20 mV
50 mA
40 mV
33 mA
60 mV
26 mA
80 mV
Voltage programming
Range:
Resolution:
Resolution:
0.009 to 9.18 V
0.84 mV
0.21 mV
0.02 to 20.4 V
1.7 mV
0.42 mV
0.04 to 40.8 V
3.5 mV
0.84 mV
0.06 to 61.2 V
5 mV
1.25 mV
0.08 to 81.6 V
6.7 mV
1.68 mV
1 Quick Reference
46 Keysight N6900/N7900 Series Operating and Service Guide
