HCOPy Subsystem
HCOPy commands return the display image.
HCOPy:SDUMp:DATA? [BMP|GIF|PNG]
Returns an image of the front panel display. The format may be specified by the optional parameter. If
no format is specified, the format is determined by HCOPy:SDUMp:DATA:FORMat.
The response is a SCPI 488.2 definite length binary block of the form: #<nonzero digit><digits><8 bit
data-bytes> where:
<nonzero digit> specifies the number of digits to follow,
<digits> specify the number of 8 bit data bytes to follow, and
<8 bit data bytes> contain the data to be transferred.
Parameter Typical Return
[BMP|GIF|PNG] <Block>
Returns the image in GIF format: HCOP:SDUM:DATA? GIF
HCOPy:SDUMp:DATA:FORMat BMP|GIF|PNG
HCOPy:SDUMp:DATA:FORMat?
Specifies the format for front panel images returned.
Parameter Typical Return
BMP|GIF|PNG, *RST PNG BMP, GIF, or PNG
Specify GIF as the image format: HCOP:SDUM:DATA:FORM GIF
Keysight RP7900 Series Operating and Service Guide 195
5 SCPI Programming Reference
