Common Characteristic All Models
Regulatory Compliance
EMC:
Safety:
Complies with European EMC Directive for test and measurement products
Complies with Australian standard and carries C-Tick mark
This ISM device complies with Canadian ICES-001
Cet appareil ISM est conforme à la norme NMB-001 du Canada
Complies with European Low Voltage Directive and carries the CE mark.
Conforms to US and Canadian safety regulations.
Declarations of Conformity for this product may be downloaded from the Web. Go to
http://www.keysight.com/go/conformity and click on “Declarations of Conformity.”
AC Input
Phase and range:
Frequency:
Input VA:
Input current per phase
200 VAC input:
400 VAC input:
Efficiency at full power:
Power Factor:
Fuse:
3 phase; 200 VAC nominal ±10%, and 208 VAC nominal ±10%
3 phase; 400 VAC nominal ±15%, and 480 VAC nominal ±10%
50/60 Hz
RP7951A, RP7961A: 6.5 kVA
RP7952A, RP7962A, RP7953A, RP7963A: 11.5 kVA
RP7951A: 17.3 A; RP7952A, RP7953A: 35 A
RP7961A: 8.66 A; RP7962A, RP7963A: 17.3 A
RP7951A, RP7952A, RP7953A: 86.3%
RP7961A , RP7962A, RP7963A: 91.5%
0.99 @ nominal input and rated power
Internal fuse - not user accessible
During a 1-cycle line dropout the unit may reboot. The output will remain off after reboot until the
operator reinstates the previous settings, either by the front panel controls or using a computer
program. This behavior is consistent with safe operating procedures.
Output Terminal Isolation: No output terminal may be more than ±950 VDC from any other terminal or chassis ground.
Typical Weight RP7951A, RP7961A: 60 lbs. (27.3 kg)
RP7952A, RP7962A, RP7953A, RP7963A: 70 lbs. (31.8 kg)
Output Impedance Graphs
All the voltage priority impedance graphs are in High bandwidth setting. There are only very minor
differences at low frequencies on the graphs in Low bandwidth setting. The bandwidth setting has no
effect in current priority mode.
Keysight RP7900 Series Operating and Service Guide 55
