4 Introduction to the Plug-In Modules for the 34980A
214 Keysight 34980A Mainframe User’s Guide
Displayed
Number...
Means This... Determined by...
1014 A MUX module is in slot 1, channel of interest
is 14. This channel is labeled on the simplified
schematics as 014 on Bank 1 of each MUX
module.
MUX module channel numbers are determined by
the numbers assigned to the switches on each
bank. Channel numbers contain three digits.
3921 A MUX or matrix module is in slot 3, channel of
interest is 921 (Analog Bus relay on ABus1)
MUX and matrix channel numbers for the Analog
Bus relays are determined by the number
assigned to the relays.
5304 A 34931A, 34932A, 34933A (2-wire mode)
matrix module is in slot 5, crosspoint is row 3,
column 4.
Matrix module (in 2-wire mode) channel numbers
are derived from the crosspoint or intersection of
rows and columns, columns having two digits).
2437 A 34933A matrix module in 1-wire mode is in
slot 2, matrix of interest is 4, crosspoint is row
3, column 7.
34933A matrix module (in 1-wire mode) channel
numbers are derived from a specific matrix
number and
the crosspoint or intersection of rows
and columns on that matrix.
