2 Getting Started
38 Keysight 34980A Mainframe User’s Guide
Front Panel at a Glance
1 The On/Standby switch is used to toggle the 34980A between On and Standby modes only. To turn the unit off, remove
the power cord.
2 The Utility key accesses menus to configure Remote I/O (LAN, GPIB, and USB) operation, set Date and Time, and
configure other system-related instrument parameters.
3 The Store/Recall key allows you to save and recall up to six instrument setups.
For proper instrument function, Channel monitor must be turn OFF
when the state is stored and Auto recall is enabled. If the Channel
monitor is turned ON, the front panel may freeze. If the front panel is
forzen, all plug-in modules must be removed and the auto-recall
function turned OFF to restore the instrument back to its initial working
state.
