2 Accessories
26 Keysight 85024A User’s and Service Guide
Replaceable parts
If the tip is discolored, bent or broken, it must be replaced. Follow the procedure
outlined in Replacing the probe tip below.
Figure 2-2 Exploded view of 10:1 divider
Replacing the probe tip
1 Remove the 10:1 divider from the probe.
2 Unscrew the damaged tip with a 3/32 nut driver supplied with the probe and
discard the tip.
3 Screw on the new tip and lightly tighten it with a 3/32 inch nut driver.
(Over-tightening the tip can damage the nose assembly.)
Item Description Part number
1 Short probe tip
Long probe tip
85024-60015
85024-60016
2 Guide 11881-20007
