Keysight 85024A High Frequency Probe
User’s and Service Guide
37
5 Performance Tests
Recommended Test Equipment 38
Network Analyzer Operation 39
Median Gain and Frequency Response Flatness 41
Gain Compression 43
Average Noise Level 46
Test Record 47
The procedures in this chapter test the probe to ensure that it meets the
warranted specifications listed in the data sheet (see “Specifications and
Characteristics” on page 19). The “Test Record” on page 47 provides space to
record the test results. Each of the tests can be performed without access to the
interior of the probe. Follow the procedures, record data on the ““Test Record” on
page 47, perform the calculations, and determine pass or fail for each test item.
All tests must pass for the performance test to be verified.
The performance tests in this chapter cover the specifications for a standard
85024A probe. If the serial number label indicates an option, contact Keysight
Technologies for applicable specifications. Refer to “Sales and Technical
Support” on page 6 for a list of Keysight Technologies sales and service offices.
