Replaceable Parts 6
Keysight 85024A User’s and Service Guide 53
Figure 6-1 Replaceable parts identification
CAUTION
Failure to remove the nose assembly prior to replacing the tip will result in
damage to the conductive elastometer on the tip assembly.
NOTE
Item 11 is a nut which slides over items 12 through 17 and screws onto the end
of the heat sink.
