Keysight E8257D/67D - Disassembled A24 67 Ghz Highband Coupler and A25 B Highband Detector Bias Board

E8257D/67D, E8663D PSG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-48
Disassembled A24 67GHz Highband Coupler and A25B Highband Detector Bias Board
Figure 2-25 Disassembled A24 67GHz Highband Coupler and A25B Highband Detector Bias Board
Table 2-11 Disassembled A24 67GHz Highband Coupler and A25 Highband Detector
Item No. Description Qty Part Number
1 Coupler Bracket (Option 550/567) 1 E8251- 00306
2 Screw- Machine M4.0 x .312 PN- PN 2 0515- 0658
3 Screw- Machine M3.0 x 8 CW- PN- TX 4 0515- 0372
