E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A23 Lowband Coupler/Detector

3-53

Figure 3-28 A23 Lowband Coupler/Detector

E8257D & E8663D – W37

A23

E8267D – W75
