Reference Waveforms
Analog channel or math waveforms can be saved to one of two reference
waveform locations in the oscilloscope. Then, a reference waveform can be
displayed and compared against other waveforms. One reference waveform can
be displayed at a time.
Table 11 Reference Waveform Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Reference waveforms,
display
[Ref] > Display Ref
Reference waveforms,
save
[Ref] > Save/Clear > Source, [Ref] > Save/Clear > Save to
Reference waveforms,
skew
[Ref] > Skew, Entry knob
Reference waveforms,
scale
[Ref] > Scale, Entry knob
Reference waveforms,
offset
[Ref] > Offset, Entry knob
Reference waveforms,
clear
[Ref] > Save/Clear > Clear
[Save/Recall] > Default/Erase > Secure Erase
Reference waveforms,
info
[Ref] > Save/Clear > Display Info
Reference waveforms,
info, transparent
background
[Ref] > Save/Clear > Transparent
Reference waveforms,
save/recall from USB
storage device
[Save/Recall] > Save > Format, Reference Waveform data (*.h5)
[Save/Recall] > Recall > Recall:, Reference Waveform data (*.h5)
