Quick Reference 2
Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide 49
Trigger Mode, Coupling, Reject, Holdoff
Noisy Signals If the signal you are probing is noisy, you can set up the oscilloscope to reduce the
noise in the trigger path and on the displayed waveform. First, stabilize the
displayed waveform by removing the noise from the trigger path. Second, reduce
the noise on the displayed waveform.
1 Connect a signal to the oscilloscope and obtain a stable display.
Table 13 Trigger Type Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Trigger level Turn the trigger Level knob.
Also: [Analyze] > Features, Trigger Levels.
The edge trigger level for the Line source is not adjustable. This trigger is synchronized with the
power line supplied to the oscilloscope.
Trigger type
[Trigger] > Trigger Type (Edge, Pulse Width, Video, Serial 1, Pattern
*
, Rise/Fall Time
*
, Setup and
Hold
*
)
Edge trigger [Auto Scale] (sets up an Edge trigger)
[Trigger] > Trigger Type, Edge
Pulse width trigger [Trigger] > Trigger Type, Pulse Wid th
Video trigger [Trigger] > Trigger Type, Video
NOTE: Many video signals are produced from 75
Ω sources. To provide correct matching to these
sources, a 75
Ω terminator (such as a Keysight 11094B) should be connected to the oscilloscope
input.
Pattern trigger [Trigger] > Trigger Type, Pattern
Rise/fall edge
transition time trigger
[Trigger] > Trigger Type, Rise/Fall Time
Setup and hold
violation trigger
[Trigger] > Trigger Type, Setup and Hold
Serial bus trigger [Trigger] > Trigger Type, Serial 1
See “Serial Bus Decode/Trigger" on page 73.
*
Pattern, Rise/Fall Time, and Setup and Hold trigger types are available on DSOX1000-Series models only
