62 Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide
2 Quick Reference
Table 19 Measurement Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Measurement type [Meas] > Type:
Snapshot all
measurements
[Meas] > Type: Snapshot All, Add Measurement
You can also configure the [Quick Action] key to display the Snapshot All popup. See “Configuring
the [Quick Action] Key" on page 85.
Voltage
measurements
[Meas] > Type: (Peak-Peak, Maximum, Minimum, Amplitude, Top, Base, Overshoot, Average, DC
RMS, AC RMS), Add Measurement
Time measurements [Meas] > Type: (Period, Frequency, Counter, + Width, – Width, Duty Cycle, Rise Time, Fall Time,
Delay, Phase), Add Measurement
The Counter measurement is available when the edge or pulse width trigger mode is selected and
the measurement source is the same as the trigger source.
Measurement
thresholds
[Meas] > Settings > Thresholds >
Also: [Analyze] > Features, Measurement Thresholds.
Measurement window [Meas] > Settings > Meas Window (Auto Select, Main, Zoom)
Clear measurements [Meas] > Clear Meas >
