System-Related Operations
Self-test
Instrument Identification
Instrument State Storage
Output Groups
Front Panel Display
Front Panel Keys
Password Protection
Self-test
A power-on self-test occurs automatically when you turn on the power system. This test assures you
that the instrument is operational. If the self-test is successful, the power system will continue to
operate normally. If the self-test fails, the front panel Err indicator comes on. Press the Error key to
display the list of errors on the front panel. Refer to Preliminary Checkout for further Information.
Front Panel Menu Reference SCPI Command
Cycle AC power. *TST?
Instrument Identification
Keysight N6700C MPS mainframes are identified by the serial number located on the interface cover.
Power module serial numbers are located on their top covers.
The serial number consists of a 10-character number (e.g. MY24D00013) located on the label on the
top of the interface board. The first two characters indicate the country of manufacture, and the last
five digits are a sequential number assigned to each mainframe.
For MPS mainframes, you can programmatically query the model number, serial number, firmware
revision, backup and active firmware. For power modules, you can programmatically query the model
number, serial number, installed options, voltage, current and power rating.
Front Panel Menu Reference SCPI Command
Select System\About\Frame
or
Select System\About\Module
For mainframe information: *IDN?
For information about the power module in channel 1:
SYST:CHAN:MOD? (@1)
SYST:CHAN:OPT? (@1)
SYST:CHAN:SER? (@1)
Note that you have the ability to change the identity of the mainframe. This functionality is only
intended for compatibility with previous "A"and "B" version mainframes.
Keysight N6700C Operating and Service Guide 159
4 Operating the Power System
