Voltage Commands
Voltage commands program the output voltage and voltage protection functions. The SOURce
keyword is optional in the following commands.
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude] <value>, (@<chanlist>)
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX,] (@<chanlist>)
[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude] <value>, (@<chanlist>)
[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX,] (@<chanlist>)
Sets the immediate voltage level and the triggered voltage level when the output is in constant
voltage mode. The triggered level is a stored value that will be programmed when a Step transient is
triggered.Units are in volts. The maximum value depends on the voltage rating of the unit.
Parameter Typical Return
0 - maximum|MIN|MAX, *RST 0
The maximum value is 102% of the voltage rating of
the power module
<voltage level>
Sets the output voltage level to 20 V: VOLT 20, (@1)
Sets the triggered voltage level to 25 V: VOLT:TRIG 25, (@1)
The query returns the programmed voltage level in the form +n.nnnnnnE+nn for each channel
specified. Multiple responses are separated by commas.
[SOURce:]VOLTage:BWIDth[:RANGe] LOW|HIGH1|HIGH2|HIGH3, (@<chanlist>)
[SOURce:]VOLTage:BWIDth[:RANGe]? (@<chanlist>)
[SOURce:]VOLTage:BWIDth:LEVel LOW|HIGH1|HIGH2|HIGH3, <frequency>, (@<chanlist>)
[SOURce:]VOLTage:BWIDth:LEVel? (@<chanlist>)
Sets the voltage bandwidth. This lets you optimize output response time with capacitive loads. Refer
to Output Bandwidth for additional information. These compensation modes only apply when the unit
is operating in voltage priority mode.
LOW - optimized for stability with a wide range of load capacitance from 0 to 150 μF
HIGH1 - provides faster up-programming speed and faster response time with load capacitance from
0–1 μF
HIGH2 - provides faster up-programming speed and faster response time with load capacitance from
0–7 μF
HIGH3 - provides faster up-programming speed and faster response time with load capacitance from
7–150 μF
<frequency> specifies the bandwidth range frequency. This setting is optional, for faster output response
time above the default frequency. The minimum frequencies are also the *RST settings.
