Keysight N777-C Series Tunable Laser Family User’s Guide 95
N777-C Instrument’s Front Panel Display 5
Figure 30 The Parameters for a Stepped Wavelength Sweep
How to Set the Repeat Mode?
The Repeat Mode determines how the instrument performs a multi-cycle
sweep.
• Select Twoway, if you want to start every odd sweep cycle at [λ Start]
and to start each even sweep cycle at [λ Stop].
• Select Oneway, if you want to start every sweep cycle at [λ Start] and to
end every sweep cycle at [λ Stop].
Figure 31 illustrates how these modes work for a three-cycle wavelength
sweep.
Figure 31 Repeat Modes
