Chapter 1 7
Preparing for Calibration and Performance Verification Test
Recommended Test Equipment
3.5mm Calibration Kit
Impedance: 50
Ω
Frequency Band: 3 GHz to 26.5 GHz
UUT: N8974A and N8975A
85052D
Synthesized Sweeper Frequency Range: 10 MHz to 26.5 GHz
Frequency Accuracy (CW): 0.02%
Power Level Range: -55 dBm
83620/30/40/50B
Option 001 or 008
Digital Multimeter Input Resistance of 10 MΩ
Accuracy of 10 mV on 100 V range
3458A
Attenuator/Switch Driver Compatible with 8494G/H Programmable
step attenuators
11713A
1 dB Step Attenuator Attenuation Range: 0 to 11 dB
Frequency Range: 50 MHz
Connectors: 3.5 mm (F)
Calibrated at 50 MHz with accuracy of
0.010 dB
8494G/H Option 2
Noise Source Frequency Range:10 MHz to 6.7 GHz
Typical ENR: 4.5 - 6.5 dB
Connection: 3.5 mm(M) or Type N
346A Std or Option
001
Noise Source Frequency Range: 10 MHz to 26.5 GHz
Typical ENR: 12.0 - 17.0 dB
Connection: 3.5 mm(M)
346C
Table 1-1 Recommended Test Equipment
Equipment description Critical specification for equipment
substitution
Recommended
model
