8 Chapter 1
Preparing for Calibration and Performance Verification Test
Recommended Test Equipment
Table 1-2 Recommended Accessories, Adaptors and Cables
Equipment description Critical specification for equipment
substitution
Recommended
model
BNC Lead (X 2) Length 122 cm (48 in.), Frequency 10 MHz 10503A
Cable 50 Type N (M to M)
Frequency Band: 3 GHz to 26.5 GHz
11500C
Cable (X 2) 10 MHz to 26.5 GHz
3.5mm (M) to 3.5 mm (M), 61 cm
(24 in.)
11500E
Microwave Cable 2 2.4 mm (M) to 2.4 mm (M), 81 cm (32 in.)
Frequency band: 3 GHz to 26.5 GHz
85133C
Adapter 50 Type N (F) to 7 mm (included in 85032B
Type N Calibration Kit)
85054-60001
Adapter 50 Type N (F) to 3.5 mm Precision (F) 1250-1745
Adapter 2.4 mm (M) to 3.5 mm Precision (F) 11901C
Adapter N8972A/N8973A Type N (M) to 3.5 mm (F)
OR
N8974A/N8975A 3.5 mm Precision (F) to
3.5 mm (F)
1250-1744
1250-1749 or
83059A
Adapter 83620/83630 3.5 mm Precision (F) to
3.5 mm (F)
OR
83640/83650 2.4 mm Precision (F) to
3.5 mm (F)
1250-1749 or
83059A
11901C
DVM Adapter BNC (F) to Dual Banana Plug (M) Adapter,
50 Ω
E9637A
BNC Lead Length 12 cm (48 in.), Frequency 10 MHz 10503A
