Kidde Fire Systems PEGAsys

August 199976-100016-001
Intelligent Suppression Control/Fire Alarm System
PEGAsys
6-1
SYSTEMS
PEGAsys Control Unit (includes CCM with One RX/TX Module, One Power Supply/ 76-100000-501
Charger Assembly and Enclosure)
PEGAsys Multi-Loop Control Unit (includes CCM with One Multi-Loop 76-100000-600
Motherboard One RX/TX Module, One P.S./Charger Assembly and Enclosure)
MAIN SYSTEM COMPONENTS
Central Control Module (CCM), Single-loop 76-100008-501
Central Control Module (CCM), Multi-loop 76-100008-600
Power Supply/Charger Assembly, includes 4 Amp. P.S., Rev. C. 76-100009-010
RX/TX Module for Single Loop System 76-100005-001
RX/TX Module for Multi-Loop System 76-100005-002
Main Enclosure 76-100000-502
INPUT/OUTPUT MODULES
Agent Release Module 76-100001-001
Signal Output Module 76-100003-001
Relay Output Module 76-100004-001
City Tie Module 76-100002-001
I/O Motherboard for 8 Option Modules 76-100007-001
I/O Multi-Loop Motherboard for up to 8 RX/TX or 7 I/O modules 76-100017-001
POWER SUPPLIES
Power Supply Module, 4 Amp., including 36" Wiring Harness (for main cabinet) 76-100009-002
Power Supply Module, 4 Amp., including 8" Wiring Harness (for expansion cabinet) 76-100009-003
ADDITIONAL COMPONENTS
PEGAsys Expansion Enclosure (order backplane separately) 76-100000-505
Expansion Backplane, for Mounting Motherboard and 4 Power Supplies 76-100000-006
Expansion Backplane, for Mounting 8 Power Supplies 76-100000-007
Expansion Backplane, for Mounting two I/O Motherboards 76-100000-008
Battery Enclosure for Additional Batteries 76-100010-001
Battery 12V, 17AH 06-115915-046
Battery 12V, 33AH 89-100052-001
CHAPTER 6
PARTS LIST
6-1 INTRODUCTION
The PEGAsys system parts list, Table 6-1 provides a list of all
repair parts.
NOMENCLATURE PART NUMBER
Table 6-1. PEGAsys System Parts List
