PASSERIES Preface P-3
Options
Below are options available for the PAS series.
For details on the options, contact your Kikusui agent or distributor.
Rack adapter
Fig.P-1 Rack adapter
For information on rack adapter mounting, see the KRA3 or KRA150
operation manual.
Remove the handle and rubber feet before you mount the PAS series
to a rack.
We recommend that you keep all pieces that you have removed from
the PAS series. You will need these pieces if you remove the PAS
series from the rack adapter.
If you remove the PAS series from the rack, re-attach the original rub-
ber feet.
• To reinstall the handle that has been removed, use screw
locking agent (e.g., 1401B by ThreeBond International, Inc.)
to prevent screws from loosening.
KRA150
Milli rack JIS standard
460
480
460(18.11)
482(18.98)
149
24.5
100
132.5(5.22)
57(2.24)
260(10.24)
260
37.75
(1.49)
KRA3
Inch rack EIA standard
Unit: mm (inch)
