PAS SERIES Remote Control 4-1
Chapter. 4 Remote Control
This chapter describes the remote control function of the unit.
Please read the warnings and cautions thoroughly before operation.
There are two main methods for remotely controlling the unit.
• Analog remote control
• Digital remote control
In analog remote control, the power supply and
contacts that are con-
nected to the J1 connector on the rear panel are used to control the
un
it.
In digital remote control, the PIA4830, PIA4850 or PIA4810 Power
S
upply Con
troller that is connected to the TP-BUS connector on the
rear panel is used to control the unit.
For details on the PIA4800 series Power Supply Controller, see the
manual of the respective product. For connection to a Power Supply
and device messages, refer to the “Connecting & Programming
Guide” in the CD-ROM that came with the PIA4800 series.
If you are using the PIA3200 Power Supply Controller, contact your
K
ikus
ui agent/distributor.
4.1 Analog Remote Control
The J1 connector on the rear panel can be used to control the unit in
the following manner.
• Control the output voltage using external voltage
• Control the output current using external voltage
• Control the output voltage
using ex
ternal resistance
• Control the output current using external resistance
• On/off control of the output using external contact
• Shutdown control using external contact
(turn off the OUTPUT or POWER switch)
