PAS SERIES Remote Control 4-21
4.2 Remote Monitoring
4.2.1 External Monitoring of the Output Voltage and
Output Current
The J1 connector consists of monitor outputs for output voltage and
output current.
Table 4-3 Monitor output of output voltage and output
cu
rrent
• Shorting V MON and I MON to A COM can cause
damage to the unit.
• Monitor output rating
Output impedance: 1 kΩ or less
Maximum output current: Approx. 10 mA
• The
monitor outputs are used to monitor the DC voltage
(mean v
alue). They cannot be used to accurately monitor the
AC components (ripple, transient response, etc.) of the actual
output voltage or current.
Pin No. Signal Name Description
1 A COM Common for remote control input and output monitor
8 V MON
M
onitor output of output voltage
0 to appr
ox.
10 V for 0 to rated output voltage
9 I MON
Monitor output of output current
0 to approx.
10 V for 0 to rated output current
