PAS SERIES Remote Control 4-23
4.3 Digital Remote Control
In addition to operating the PAS from the front panel, you can use a
power supply controller (PIA4830/PIA4850/PIA4810) to remotely
control the PAS via the USB, GPIB or RS232C interface.
• Version 2.10 or later is required for the PIA4800 series. If you
are using an earlier version, you need to upgrade. For details,
contact your Kikusui agent/distributor.
You can confirm a version of the PIA4800 series through the
IDN?.
4.3.1 Connecting of the Power Supply Controller and
Device messages
The PAS and power supply controller are connected via a TP-BUS.
Up to 32 devices can be connected to the TP-BUS.
To digital remotoly contorol the unit, You must set CV control and
CC control of CONFIG settings to “0” (panel control).
For details on CONFIG Setting, See "3.2.4 Unit Configuration
(CONFIG)"
For connection to a Power Supply Controller and device messages,
refer to the “Connecting & Programming Guide” [index.html] in the
CD-ROM that came with the PIA4800 series.
The “Connecting & Programming Guide” is HTML format. Micro-
soft Internet Explorer or Google Chrome is required to view the
HTML files.
The list of messages and connection of power supply of Connecting
& Programming guide is provided in a PDF file. Adobe Reader is
required to view the PDF files.
The latest version of the “Connecting & Programming Guide” can be
downloaded from Web site (http://www.kikusui.co.jp/en/download/).
NOTE
