3.2.2 Setting the OVP (Overvoltage Protection) Trip
Point
The OVP function protects a load from unexpectedly high voltage.
When OVP is activated, "ALM" on the display lights, and the OUT-
PUT is turned off or the POWER switch is tripped. (Selectable range:
10 % to 110 % of the rated output voltage)
For details on setting whether to turn off the OUTPUT or trip the
POWER switch when OVP is activated, see "POWER switch trip
when the protection circuit is activated (DEGIT H)" in "3.2.4 Unit
Configuration (CONFIG)".
If the POWER switch trip is set to enable when the protection circuit
is activated in CONFIG, the illumination of "ALM" and the ALARM
signal output is held for approximately 0.5 s.
To release the alarm when the POWER switch is not set to trip when
the protection circuit is activated in CONFIG, turn off the POWER
switch once.
• The OVP trip point is factory-preset to approximately 110 %
of the rated output voltage of the unit. When using the unit,
set an appropriate OVP trip point for the load.
• When checking the OVP operation, the unit must be started
w
ith
the OUTPUT turned off. Therefore, check that PWR
ON OUTPUT in the CONFIG settings is set to "0." For
details on CONFIG settings, see "3.2.4 Unit Configuration
(CONFIG)".
• The OVP function of the unit operates against the output ter-
minal voltage. If you wish to operate the function against the
v
oltage across the load
, set the OVP trip point by considering
the voltage drop of the load cable.
Setting the OVP trip point
1. Check that no load is connected to the output terminal.
Since we
will check the OVP operation by actually outputting a
voltage after setting the OVP trip point, remove the load.
2. Turn on the POWER switch.
3. Check that the OUTPUT OFF is illuminated.
NOTE
