PAS SERIES Before Using the Unit 2-11
Fig.2-10When the output terminal is not grounded
+
–
+
+S
–S
–
+
–
+
–
17
23
22
26
6
5
2
16
3
4
1
AC
INPUT
DC
OUTPUT
J1
SENS
L
N
When remote sensing is not used:
Connect to - (neg.) output terminal
When remote sensing is used:
Connect to -S terminal of sensing
Approx. the same potential
as the - (neg.) output terminal
26 Approx. the same potential
as the - (neg.) output terminal
23 Approx. the same potential
as the + (pos.) output terminal
Insulated
Load
Rext
PAS SERIES
Vext
Since the output terminal is
floating, the section indicated
in gray must have an insulation
capacity that is greater than the
isolation voltage of the unit
with respect to the chassis.
