4-10 Remote Control PAS SERIES
■ External resistor (Rext) connection
Pins 1 and 6 of the J1 connector are used.
Fig.4-3 Connection of the output voltage control using
e
xte
rnal resistance
J1
125
26
13
1426
2-core shielded or
twisted-pair wire
Rext
