4-16 Remote Control PAS SERIES
■ External resistor (Rext) connection
Pins 1 and 7 of the J1 connector are used.
Fig.4-6 Connection of the output current control using
exte
rnal resistance
J1
1725
2
13
1426
2-core shielded or
twisted-pair wire
Rext
