PAS Ratio Modify
To modify the value of PAS ratio will meet the
different requirements.
Take the 1 level for example, “45-55 percent” is the
range value, bottom value can be modified, and the default
is 50 percent. MODE is used to confirm and turn to the next
PAS ratio setting. After all PAS ratio inputted, please hold
MODE over 2 seconds to confirm the modification and turn
to controller Over-current Cut setting (MODE back to pedal
assistant level select page). For the details, please see
Attached List 4.
PAS Ratio Page
Controller Over-Current Cut Setting
CUR means current. CUR value can be changed from
7.0A to 22.0A. Press UP/DOWN is to change the value of
the current, and hold MODE to confirm the setting and turn
to PAS sensor setting.15A is the default value of controller
over-current cut.
According to the different controller, the value
might not be able to be 22A.
