3-POINT HITCH IMPLEMENT OPERATION
4. Fast dump
The fast dump function is activated
when the joystick lever is pushed
one position further to the right
from the dump position.
5. Down & roll back
The boom can be lowered and the
bucket can scoop up by operat-
ing the joystick lever to the front
left position (10 o’clock position).
However, the operation time may
not be shortened much since the
boomisloweredrstandthenthe
bucket is rolled back due to unbal-
anced hydraulic pressure in the
hydraulic circuit.
6. Down & dump
The boom can be lowered and the
bucket can dump by operating the
joystick lever to the front right posi-
tion (2 o’clock position). However,
these two operations may not be
performed simultaneously due to
unbalanced hydraulic pressure in
the hydraulic circuit.
7. Up & roll back
The boom can be lifted and the
bucket can scoop up by operating
the joystick lever to the rear left
position (7 o’clock position). How-
ever, these two operations may not
be performed simultaneously due
to unbalanced hydraulic pressure
in the hydraulic circuit.
8. Up & dump
The boom can be lifted and the
bucket can dump by operating the
joystick lever to the rear right posi-
tion (5 o’clock position). However,
the operation time is may not short-
ened much since the bucket dumps
rstandthentheboomislifteddue
to the unbalanced hydraulic pres-
sure in the hydraulic circuit.
9. Locking/unlocking joystick
Pressing the joystick lock lever in
locks the joystick while pulling it
outward unlocks the joystick as
showninthegure.

Do not leave the tractor with the
boom "OFF" the ground in any
circumstances. If it is neces-
sary, lock the joystick.

When the joystick lever is not
in use, lock it since the imple-
ment can fall down if the lever
is operated accidently.
WARNING

If the boom or bucket is not
operating, properly, lower the
bucket onto the ground, stop
the engine, and relieve all hy-
draulic pressure. Then, check
all the hydraulic connections
and connect them again.

Before connecting or disconnect-
ing the hydraulic hose coupling
from the loader, lower the boom
onto the ground, stop the en-
gine, and move the joystick lever
front and back, left and right for
several times to remove residual
pressure in the hydraulic hose.
IMPORTANT
M46-EU,AU-06.indd 15 2012-01-18 오후 6:39:15

Kioti CS2610 Specifications

General

Engine Power	24.5 hp
Engine Type	3-cylinder diesel
Transmission	Hydrostatic
Drive	4WD
Gears	Infinite (2-range)
Front tire size	18x8.5-10
PTO Speed	540 RPM
Hydraulic System Type	Open center
3-Point Hitch Category	Category 1
Fuel Capacity	6.6 gal
Rear tire size	26x12.0-12
Turning Radius	8.2 feet
