KLR.950 Revision: 2023-10-06
Serial numbers: 3008 – beyond
KLR.00001 – beyond
19
5.5.1: Breakoff delay
Time the machine is waiting before breaking the clip after the bag sensor as been triggered. However,
the machine is only starting this delay when the sensor is triggered back off (at the end of the bag).
When the bag is lifting the sensor finger, the sensor is sending the signal. A too short value will result in
a bag not completely fitted in the clip. On the other hand, a too long value will retain the product and
leave it sideways.
5.5.2: Feed after lead qty
When the user is loading clips into the machine ("load" button), it will count this number to present one
clip in the receiving position. 4 is the factory setting. If the machine is equipped with a printer (ink jet or
air printer), the value will affect how many clips it needs to print as well.
Multiple pieces have been removed to clarify the
